| Layer Metadata |  |
 |
| ||
Metadata for Drying Reefs - GBRMPA
| Data Set | ||
| DSIN | 10030 | |
| Title | Drying Reefs - GBRMP | |
| Custodian | Great Barrier Reef Marine Park Authority | |
| Jurisdiction | Great Barrier Reef | |
| Description | ||
| Abstract | Tidal, Drying or Emergent reef areas of major CORAL REEF structures within the Great Barrier Reef World Heritage Area; details those reef areas which may be submerged or exposed during tidal fluctuations from HAT to LAT. | |
| Search Word(s) | Coral, Reef | |
| Geographic Extent Name(s) | Great Barrier Reef | |
| Coordinates | N: -10.3999 | |
| S: -24.5 | ||
| E: 151 | ||
| W: 142 | ||
| Data Currency | ||
| Beginning date | 1/01/1989 | |
| Ending date | 29/11/1999 | |
| Dataset Status | ||
| Progress | Complete | |
| Maintenance and update frequency | As required | |
| Access | ||
| Stored Data Format | DIGITAL - ARC/INFO, DIGITAL - ARC/INFO Export | |
| Available Format Type | DIGITAL - ARC/INFO, DIGITAL - ARC/INFO Export | |
| Access Constraint | QFS Use Only - Dataset available on CHRIS, not for release outside QFS | |
| Data Quality | ||
| Lineage | Produced under specific contract for GBRMPA by AUSLIG. Derived from datasets produced by the Division of National Mapping. Hydrographic survey techniques used in conjunction with analysis of Landsat Panchromatic Imagery and Aerial Photographic interpretation. Supplied by AUSLIG as a line-only dataset to provide reef morphology detail; subsequent development has produced a polygon coverage, coincident with GBRMPA’s REEFS, ISLANDS and COAST datasets. | |
| Positional Accuracy | +/- 125 metres as per 250k nominal scale; DRYREEF coverage has not been statistically tested with precision survey techniques. Positional accuracy varies considerably and dataset should NOT be used for navigation purposes. | |
| Attribute Accuracy | DRYREEF has no useable attributes without further dataset development. | |
| Logical Consistency | DRYREEF is spatially coincident at nominal scale with GBRMPA’s REEFS, ISLANDS and COAST datasets. | |
| Completeness | Exposed portions of major reef systems are present. Minor exposed reefs may not be present. | |
| Contact Information | ||
| Contact Organisation | Great Barrier Reef Marine Park Authority | |
| Contact Position | Geographical Information Systems Manager | |
| Mail Address | 2 - 68 Flinders Street, PO Box 1379 | |
| Locality | Townsville | |
| State | Qld | |
| Country | Australia | |
| Postcode | ||
| Telephone | 4750 0700 | |
| Facsimile | 4772 6093 | |
| Electronic Mail | gis@gbrmpa.gov.au | |
| Metadata Date | ||
| Creation Date | 21/06/2000 | |
